Dual Solenoid Valve
>
Monitor Type
AHC-1 1/2M, 1 1/4M
Condition New
CNC or Not Normal
Power Source Mechanical
Place of Origin Seoul, South Korea
Brand Name An-Hyup Control
View other products
AHC - 3/4M, 1/2M
As factory automation and industrial automation fields are growing, the pneumatic solenoid valves used in these fields are becoming more important as well.
As safety is the top priority in the pneumatic system, An-Hyup Control has devleoped a dual valve to enhance the safety level.
The dual solenoid valve of An-Hyup Control has passed several tests on vaious features flow features, dynamic performance, temperature increase, insulation resistance, inner voltage, power consumption, air leakage, surge, gressure resistance and duravility performed by the Korea Institute of Industral Technology of the Ministry of Commerce, Industry and Energy.
The dual solenoid valve also paased the feature test and the technical review process of the Korea Institute of Industral Technology.
To manufacture better quality products, An-Hyup Control has co-developed and applied devices for the flow feature test and the dynamic performance test with Korea Institute of Industral Technology as meeting the Korean Industrial Standard.
Model
AHC-1 1/2M
AHC-1 1/4M
Tube Joint Aperture
PT 1 1/2
PT 1 1/4
Weight
13kg
Pressure Used
3.5 ~8kgf
Temperature Used
5c ~ 50c
Numbers of Operation
Within 90 times / minute
Rated Voltage of Coils
AC 110V, AC 220V, DC24V 60HZ
Allowable scope voltage
Within +,- 10% of rated voltage
Response speed
Within 0.01ms~0.012 ms
Power Consumption
20VA
