Home > PRODUCT > Dual Solenoid Valve > Large Type

AHC-1 1/2 , AHC-1 1/4

Weight 11kg
Pressure Used 3.5 ~ 8kgf
Temperature Used 5c ~ 50c
Numbers of Operation Within 90 times / minute
Rated Voltage of Coils AC 110 ~ 220V 60HZ
Allowable scope voltage Within +,- 10% of rated voltage
Response speed Within 0.01ms~0.012 ms
Power Consumption 20VA





As recently factory automation and industrial automation field are rapidly growing, the importance of pneumatic solenoid valves used in these fields is extended. As safety has to be the top priority in pneumatic system, AHC has developed the first dual valve product to enhance the safety level. The Dual Solenoid Valve of AHC has passed the variety safety tests such as features-flow features, dynamic performance, temperature increase, insulation resistance, inner voltage, power consumption, air leakage, surge, pressure resistance, and durability-performed by the Korea Institute of Industrial Technology of the Ministry of Commerce, industry and Energy.
The dual solenoid valve also passed the feature test and the technical review of the Korea Institute of Industrial Technology.
To manufacture better-quality products, AHC has co-developed and applied devices for the flow feature test and the dynamic performance test with Korea institute of industrial technology as meeting the Korea Industrial Standard.
